Reax 20-8 Rotary Mixer for 8 Bottles | 1–16 rpm | DIN 38414
Rotary mixer for 8 bottles simultaneously. Variable-speed motor, 1 to 16 rpm. Tension-spring clamps accept wide-neck vessels up to 136 mm diameter and 160–270 mm in height. Compliant with DIN 38414 for wastewater and sludge analysis. IP 21 protection with automatic overload cutoff. Operating range: 0 °C to 40 °C, max. 80% relative humidity.
In stock
SKU:
5054128
€4,324.58
Reax 20-8 Rotary Mixer for 8 Bottles
Continuous rotary mixer with capacity for 8 bottles. Variable-speed motor, 1 to 16 rpm, delivers consistent, smooth rotation. Compliant with DIN 38414 for wastewater and sludge examination.
Key Features
- Capacity: 8 bottles simultaneously — mixed vessel types and sizes
- Speed: 1 to 16 rpm, rheostat-controlled
- Clamping: Tension-spring mechanism — accepts wide-neck vessels up to 136 mm diameter
- Vessel height range: 160 to 270 mm
- Standard: DIN 38414, Part 4
- Motor protection: Automatic overload cutoff
Applications
Designed for wastewater and sludge examination per DIN 38414, Part 4. Suitable for any application requiring gentle, continuous rotation of multiple samples — extractions, homogenisation, incubation.
Tension-spring clamping allows mixed vessel formats without reconfiguring the unit.
Technical Specifications
- Rotation speed: 1 to 16 rpm
- Bottle capacity: 8
- Max. vessel diameter: 136 mm
- Vessel height: 160 to 270 mm
- Ambient temperature: 0 °C to 40 °C
- Max. relative humidity: 80%
- Protection class: IP 21
- Control: Illuminated on/off switch
- Reference standard: DIN 38414, Part 4
| Brand | Heidolph |
|---|
