L-4B Water Bi-distiller 4 L/h Borosilicate with Automatic Protection
Continuous bi-distiller, 4 litres/hour, borosilicate glass construction. Easy access to glassware and heating elements. Two stages in series for pyrogen-free bi-distilled water. Quartz heating elements. Protection: overheating, electrical cut-off, maximum fill level. Wall-mountable.
In stock
SKU:
5903001
€2,961.20
€2,813.14
L-4B Water Bi-distiller 4 L/h Borosilicate with Automatic Protection
Automatic bi-distiller, 4 litres/hour. Two chambers in series: distillate from the first passes to the second once the correct level is reached, yielding high-purity water.
Construction and Heating
- Material:Borosilicate glass. Resistant to chemical corrosion and thermal shock.
- Protective housing:Direct access to glassware and heating elements.
- Heating elements:4 quartz elements.
- Installation:Wall-mounting bracket included.
Safety Systems
Three independent protections against common failure modes:
- Overheating pressure switch:Activates on water loss; resets automatically when supply is restored.
- Water inlet cut-off:Interrupts flow in the event of electrical failure.
- Maximum level disconnect:Cuts power and water supply when the reservoir is full—prevents overflow.
Electrical Specifications
Configurable to suit site electrical installation:
- 230 V / I, 50/60 Hz:38.6 A.
- 230 V / III, 50/60 Hz:22 A.
- 230 V / III+N, 50/60 Hz:12.72 A.
Typical Applications
Process water for analytical laboratories, microbiology, and culture media preparation. Fully automatic operation—suited to unattended production runs.
| Brand | OPTIC IVYMEN SYSTEM |
|---|
